Processor
|
-
5th Generation Intel Core i5-5200U 2.2 GHz (max turbo frequency 2.7-GHz), 3 MB L3 cache, 15W
-
5th Generation Intel Core i5-5300U 2.3 GHz (max turbo frequency 2.9-GHz), 3 MB L3 Cache, 15W
-
5th Generation Intel Core i7-5500U 2.4 GHz (max turbo frequency 3.0-GHz), 4 MB L3 Cache, 15W
-
5th Generation Intel Core i7-5600U 2.6 GHz (max turbo frequency 3.2-GHz), 4 MB L3 Cache, 15W
note:
Multi-Core is designed to improve performance of certain software products. Not all customers or software applications will necessarily benefit from use of this technology. 64-bit computing on Intel® architecture requires a computer system with a processor, chipset, BIOS, operating system, device drivers, and applications enabled for Intel® 64 architecture. Processors will not operate (including 32-bit operation) without an Intel® 64 architecture-enabled BIOS. Performance will vary depending on your hardware and software configurations. Intel’s numbering is not a measurement of higher performance.
Not available with Intel iAMT (*Not available with vPro)
Processor speed denotes maximum performance mode; processors will run at lower speeds in battery optimization mode.
|
Chipset
|
Chipset integrated with processor
|
Graphics
|
-
Integrated: Intel HD* Graphics 5500
-
Discrete: AMD Radeon R7 M260X, with 1 GB dedicated DDR5 video memory**
note:
*HD content required to view HD images.
**AMD Dynamic Switchable Graphics technology requires an Intel processor, plus an AMD Radeon discrete graphics configuration and is not available on FreeDOS and Linux OS. With AMD Dynamic Switchable Graphics technology, full enablement of all discrete graphics video and display features may not be supported on all systems (e.g. OpenGL applications will run on the integrated GPU or the APU as the case may be).
|
Display
|
Internal:
Non touch
-
14.0″ diagonal LED-backlit HD anti-glare SVA flat (1366 x 768)
-
14.0″ diagonal LED-backlit HD anti-glare SVA flat (1366 x 768) with camera
-
14.0″ diagonal LED-backlit HD+ anti-glare SVA flat (1600 x 900)
-
14.0″ diagonal LED-backlit HD+ anti-glare SVA flat (1600 x 900) with camera
-
14.0″ diagonal LED-backlit FHD anti-glare UWA slim (1920 x 1080)
-
14.0″ diagonal LED-backlit FHD anti-glare UWA slim (1920 x 1080) with camera
Touch
External:
Up to 32-bit per pixel color depth
VGA:
Port supports resolutions up to 1920 x 1200 external resolution at 75 Hz
DisplayPort
Supports resolutions up to 3840 x 2160 at 60Hz. Supports Multi-Stream Transport (MST) where three displays can be daisy chained with digital displays through DisplayPort Only. The full resolution of each display will be limited as you reach 3 displays due to the bandwidth limitations with a maximum resolution of:
Number of Displays supported
3 With Optional* 2013 UltraSlim Docking Station
|
Storage and drives
|
Primary storage bay:
HP 3D DriveGuard (Windows only)
HP 3D DriveGuard mitigates the risk of hard drive failures, safeguarding your data when you are on the go by sensing sudden movement and protecting the hard drive. The hard drive is mounted directly to the notebook frame, reducing the transmission of shock to the hard drive.
note:
*For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 16 GB (for Windows 7) and 30 GB (for Windows 8) of system disk is reserved for the system recovery software.
|
Flash cache
|
note:
Available only with standard non-SED hard drive and non-solid state drives.
|
Memory
|
Standard:
-
DDR3L SDRAM (1600 MHz)
-
Two SODIMM slots supporting dual-channel memory
-
4 GB Total System Memory (4 GB x 1)
-
8 GB Total System Memory (4 GB x 2)
Maximum:
Upgradeable to 16 GB with optional 8 GB SODIMMs in slots 1 and 2*
Dual-channel:
Maximized dual-channel performance requires SODIMMs of the same size and speed in both memory slots.
note:
* Maximum memory capacities assume Windows 64-bit operating systems or Linux. With Windows 32-bit operating systems, memory above 3 GB may not all be available due to system resource requirements.
Due to the non-industry standard nature of some third-party memory modules, we recommend HP branded memory to ensure compatibility. If you mix memory speeds, the system will perform at the lower memory speed.
|
Networking and Communications
|
Wireless
Support for a broad range of secure, integrated wireless LAN and wireless WAN options featuring support for the latest industry standards. Broadband Wireless (WWAN) requires a Windows operating system and is available in select countries as a standard, factory configurable feature only. Integrated Bluetooth is also available (factory configurable only) and can be combined with any of the supported wireless LAN and wireless WAN options.
Broadband Wireless (WWAN)*
-
HP lt4112 LTE/HSPA+ Qualcomm Gobi 4G Module
-
HP lt4211 LTE/EV-DO/HSPA+ Qualcomm Gobi 4G Module**
-
HP hs3110 HSPA+ Mobile Broadband Module
note:
*WWAN is an optional feature sold separately or as an add on feature. WWAN connection requires wireless data service contract, network support, and is not available in all areas. Contact service provider to determine the coverage area and availability. Connection speeds will vary due to location, environment, network conditions, and other factors.
**4G LTE WWAN is an optional feature, not available on all products, in all regions and requires separately purchased service contract. Check with service provider for coverage and availability. Connection speeds will vary due to location, environment, network conditions, and other factors.
Wireless LAN (WLAN)*
-
Intel Dual Band Wireless-AC 7265 802.11 ac (2X2) Wi-Fi + Bluetooth
-
Intel Dual Band Wireless-7265AN 802.11 a/b/g/n (2X2) Wi-Fi + Bluetooth
-
Intel Dual Band Wireless-AC 3160 802.11 ac (1×1) Wi-Fi + Bluetooth
note:
*Wireless access point and Internet service is required and is not included.
Availability of public wireless access points limited.
Communications
Intel I218LM Gigabit* Network Connection (10/100/1000 NIC)
note:
*The term “10/100/1000” or “Gigabit” Ethernet indicates compatibility with IEEE standard 802.3ab for Gigabit Ethernet, and does not connote actual operating speed of 1 Gb/s. For high-speed transmission, connection to a Gigabit Ethernet server and network infrastructure is required.
Optional Near Field Communication (NFC)
|
Audio
|
-
HD Audio with DTS Studio Sound
-
2 Integrated stereo speakers
-
Integrated dual-microphone array; located in the display
-
Function keys for microphone mute, volume up, volume down
-
Stereo headphone/line out
-
Stereo microphone/line in
|
Webcam
|
Optional* 720p HD** webcam
-
HD format (widescreen)
-
Supports videoconferencing (non-HD) and still image capture
-
High quality fixed focus lens
-
Video capture at various resolutions up to 1280 x 720 resolution (720p) and up to 30 fps
-
M-JPEG compression supports higher frame rates for video capture and videoconferencing
-
Improved low light sensitivity
-
Improved dynamic range
-
Skype-ready***
note:
*Sold separately
**HD content required to view HD images
***Internet access required
|
Keyboard
|
The HP spill-resistant keyboard is designed using a thin layer of Mylar film under the keyboard and includes an all-metal keyboard deck for greater rigidity, as well as HP DuraKeys. The 101/102-key compatible keyboard features a full-pitch key layout with desktop keyboard features, such as editing keys, both left and right control and alt keys, and function keys. US and International key layouts are available. Backlit keyboard available as an option.
|
Pointing devices
|
Touchpad with scroll zone, on/off button with LED indicator, two-way scroll, two pick buttons.
|
Buttons and function keys
|
Separate discrete buttons provide easy access to WLAN on/off and speaker mute. Function keys provide control of features including: standby mode, display brightness, external display, microphone mute, volume down, and volume up.
|
